Battery Cable Heat Shrink Tubing - 3/8" x 3" - Black/Red (2-Pieces Combo Pack)

BHW is coated internally with a dual-purpose thermoplastic liner which flows and encapsulates when heated. When cooled, the tubing offers the mechanical strength of a superior adhesive and the corrosion protection of a high-quality mastic. Insulation varies with different types of wires, different diameters or tubing may be required. When choosing a size, consider any components or connectors that may need to be covered.

Features:

Highly abrasion and impact-resistant
Easy installation, shrinks when heated over 120 °C
The thermoplastic liner will adhere to PVC, neoprene and polyolefin, EPR, steel, and aluminum
A sturdy, heavy wall tubing with excellent insulating, abrasion-resisting, and strain-relieving properties. The thermoplastic adhesive provides superior environmental protection.
Any connection in harsh conditions
Adhesive lining provides a barrier against contaminants
Excellent resistance to acids and alkalis
Good resistance to fuel, oil, and solvents

Applications:

Splice sealing
Primary insulation
Cable/jacket repair
Direct burial/submersible
Strain relief

Compliances:

MIL-I-23053/15 Class 2

Specifications:

Type: Heat Shrink
Box Dimensions: 1"H x 2"W x 3"L WT: 0.01 lbs
UPC: 840248214797
