ECHOMAP™ UHD2 93SV LiveScope™ Plus Ice Fishing Bundle LI with ECHOMAP™ UHD2 93sv, LiveScope Plus System & Lithium-ion Battery

Get improved resolution, reduced noise, clearer images, and better target separation with the LiveScope™ Plus Ice Fishing Bundle LI. It includes a 9-inch ECHOMAP™ UHD2 combo, the complete LiveScope Plus System with LVS34-IF transducer, swivel pole mount, and a lightweight lithium battery.

Features:

Get improved clarity, sensitivity, and Target Separation
Scan surroundings with reduced noise and fewer sonar artifacts
Use LiveScope™ forward mode so you know where to drill
Use LiveScope™ down mode so you can keep an eye on your jig and the fish
Fish longer with a 16.5AH lightweight lithium-ion battery
Includes a rugged, portable carrying case
LiveScope™ Forward sonar shows up to 200’ all around you and below the ice, so you can locate schools of fish and know where to drill the next hole
LiveScope™ Down sonar shows live sonar images of what is below the ice, so you can watch fish respond to your jig
Where you take your bundle is up to you. But the rugged, portable carrying case lets you easily transport it from hole to hole and season to season

ECHOMAP UHD2 Combo

Revolutionary real-time sonar pairs with a large 9-inch ECHOMAP UHD2 combo touchscreen display with a keyed assist, allowing you to see up to 200’ in any direction.

Two Modes One Transducer

LiveScope System offers two live-scanning sonar modes — Down and Forward. It features a transducer cable that stays flexible, even in freezing conditions

Garmin Navionics+ Maps

You get preloaded Garmin Navionics+ maps for exceptional detail on more than 23,000 U.S. lakes.

Custom Combos

You can create custom pages that combine sonar, flashers, and maps on your display.

Lithium Battery

Fish even longer with a lightweight 16.5Ah lithium battery that won’t weigh you down on the ice.

In the Box:

ECHOMAP™ UHD2 chartplotter (version depends on mapping selected)
LVS34-IF transducer
GLS™ 10 sonar module
Ice fishing pole mount
Tilt mount
Power cable
Portable fishing bag with a handle
Lithium-ion battery
Battery charger
Documentation

General Specifications:

Dimensions: 13.8 x 12.2 x 13.0 in. / 35 x 31 x 33 cm
Touchscreen: Yes
Input: Touchscreen with Keyed Assist
Display Size: 7.8 x 4.5, 9.0" in. / 19.8 x 11.5, 22.9 cm
Display Resolution: 1024 x 600 pixels
Display Type: WVGA, IPS
Weight: 22.5 lbs / 10.2 kg
Waterproof: IPX7

Maps & Memory:

Accepts Data Cards: 1 microSD™ card; 32 GB maximum size
Waypoints: 5000
Track Points: 50,000
Tracks: 50 saved tracks
Navigation Routes: 100

Ice Fishing Details:

Battery Type, Size: Lithium-ion, 16.5Ah
Bag Size: Extra Large (XL)
Included Transducer: LiveScope™ Plus System with LVS34-IF
Transducer Holding Feature: Pole mount

Sensors:

Has Built-in Receiver: Yes
Receiver: 10 Hz
NMEA 2000 Compatible: Yes
GPS: Yes
Glonass: Yes
Galileo: Yes
Beidou: Yes
Supports Waas: Yes
Supports Multi-Band, Multi-Constellation GPS: Yes

Built-in Maps:

Built-in Auto Guidance+: Yes (downloadable via ActiveCaptain app)
Garmin Navionics+ Inland & Coastal: Yes (see Additional)
Garmin Navionics+ (Inland): Yes (see Additional)

Optional Map Support:

Garmin Navionics+: Yes
Garmin Navionics+ VIision+™: Yes
TOPO: Yes
Standard Mapping: Yes
Garmin Quickdraw Contours: Yes

Chartplotter Features:

ActiveCaptain® Compatible: Yes

Electrical Features:

Power Input: 9 to 18 Vdc

Sonar Features & Specifications:

Displays Sonar: Yes
Power Output: 500 W
Traditional Sonar (Dual Frequency/Beam): Built-in (single channel CHIRP, 50/77/83/200 kHz, L, M, H CHIRP)
ClearVü™: Built-in 260/455/800/1000/1200 kHz
SideVü™: Built-in 260/455/800/1000/1200 kHz
Panoptix™ Sonar: Yes
Livescope; Yes

Connections:

NMEA 2000® Ports: Yes
Garmin Marine Network Ports: 1
12-Pin Transducer Ports: 1
Bluetooth® Pairing: Yes
Ant+ (Connectivity): Yes
Garmin Wi-Fi Network (Local Connection): Yes

Additional:

Garmin Navionics+ Inland & Coastal: 95sv Canada
Garmin Navionics + (Inland): 95sv U.S. Lakes

Warning WARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov.

Specifications:

Included Transducer: LiveScope™ Plus System with LVS34-IF
Screen Size: 9"
Touchscreen: Yes
Transducer Included: Yes
Box Dimensions: 15"H x 17"W x 20"L WT: 32.3 lbs
UPC: 753759322748
